CSPF: 5 Stars Unit Code: Indoor Unit Code: AR10CYEAAWKNTC Outdoor Unit Code: AR10CYEAAWKXTC Capacity (Cooling/ kJ/H) 10600 kJ/H Capacity (Cooling/ Min - Max kJ/H) 3/000 - 11500 kJ/H EER (Cooling/ kJ/hw) 13.25 kJ/hw CSPF 5.41 Energy Star Rating (Cooling) 5 Star Noise Level (Indoor High/Low dBA) 39 / 20 dBA Noise Level (Outdoor/ High/Low/ dBA) 48 dBA Power Source(/V/Hz) 1 / 220~240 / 60 Power Consumption(Cooling/ W) 800W Operating Current (Cooling A) 3.8 A Loading Quantity (20/40/40Hft Without Pipe) 120 / 248 / 280 Piping Length (Max/ M) 15m Piping Height (Max/ M) 8m SVCValve (Liquid (Odxl)) 6.35 SVC Valve (Gas (Odxl)) 9.52 Moisture Removal (L/Hr) 1.1 L/Hr Air Circulation (Cooling/ ? Min) 10.7 ? Min Refrigerant (Type) R32 Refrigerant (Charging/ kg) 0.50 kg Low Ambient (Cooling/ C) 16~46 C Outdoor Unit (Compressor Type) BLDC Outdoor Unit (Anti-Corrosion Fin): Yes
SmartThings App. Remotely control the Samsung AR10CYEAAWKNTC from anywhere as the SmartThings App offers the most convenient and efficient way to make your cooling experience easy and effortless. Turn on the AC right before you get home so you can finally relax the minute you step inside your room or you can turn it off, adjust the temperature, and many more. Optimized Energy. The Premium Inverter feature regulates the compressor speed which results in even greater energy savings. Plus, it has a quiet operation that effectively provides efficient and consistent cooling. WindFree Cooling. The WindFree Cooling feature provides a more comfortable and energy-efficient cooling experience. It creates a gentle and even airflow that feels more natural and less drafty than the usual blasting of cold air directly at you. Good Sleep Mode. Get a good night's sleep while increasing your energy savings. The Good Sleep Mode adjusts the temperature as you fall deep into your sleep. It uses less power yet provides enough coolness to give you a comfortable temperature. AI Auto Cooling. The AI Auto Cooling provides an optimized energy-efficient operation by adjusting the temperature and airflow. It helps lower the power run which can result in significant savings on your electricity bill. Dehumidification Function. Remove excess moisture from the air with the dehumidification feature. It reduces the moisture in the air, making it more comfortable and less sticky. Plus, it helps prevent the growth of bacteria like mold and milde
Remote Control / Smart Control (Wi-Fi / App-enabled) / Inverter / Energy-Saving / Eco Mode
