CSPF: 5 Stars Unit Code: Indoor Unit Code: AR18CYEAAWKNTC Outdoor Unit Code: AR18CYEAAWKXTC Capacity (Cooling/ kJ/H) 19000 kJ/H Capacity (Cooling/ Min - Max/ kJ/H) 5/300 ~ 21/500 kJ/H EER (Cooling/ kJ/hw) 10.05 kJ/hw CSPF 5.2 Energy Star Rating (Cooling) 5 Star Noise Level (Indoor/ High/Low/ dBA) 42/26 dBA Noise Level (Outdoor/ High/Low/ dBA) 52 dBA Power Source(/V/Hz) 1 / 220-240 / 60 Power Consumption(Cooling/ W) 1890 W Operating Current(Cooling/ A) 8.8 A Loading Quantity (20/40/40Hft Without Pipe) 96 / 194 / 222 Piping Length (Max/ M) 30m Piping Height (Max/ M) 15m SVC Valve (Liquid (Odxl)) 6.35 SVC Valve (Gas (Odxl)) 12.7 Moisture Removal (L/Hr) 2.0 L/Hr Air Circulation (Cooling/ ? Min) 14.2 ? Min
SmartThings App. Remotely control the Samsung AR18CYEAAWKNTC from anywhere as the SmartThings App offers the most convenient and efficient way to make your cooling experience easy and effortless. Turn on the AC right before you get home so you can finally relax the minute you step inside your room or you can turn it off, adjust the temperature, and many more. Optimized Energy. The Premium Inverter feature regulates the compressor speed which results in even greater energy savings. Plus, it has a quiet operation that effectively provides efficient and consistent cooling. WindFree Cooling. The WindFree Cooling feature provides a more comfortable and energy-efficient cooling experience. It creates a gentle and even airflow that feels more natural and less drafty than the usual blasting of cold air directly at you. Good Sleep Mode. Get a good night's sleep while increasing your energy savings. The Good Sleep Mode adjusts the temperature as you fall deep into your sleep. It uses less power yet provides enough coolness to give you a comfortable temperature. AI Auto Cooling. The AI Auto Cooling provides an optimized energy-efficient operation by adjusting the temperature and airflow. It helps lower the power run which can result in significant savings on your electricity bill. Dehumidification Function. Remove excess moisture from the air with the dehumidification feature. It reduces the moisture in the air, making it more comfortable and less sticky. Plus, it helps prevent the growth of bacteria like mold and mildew
Energy-Saving / Eco Mode / Fast Cooling / Inverter
User Manual
