Capacity (Horsepower): 3.0 HP (PK) Cooling Capacity (Rated): 32,000 Btu/h or 9.37 kW Power Source: 1 Phase, 220-240 V, 50Hz / 60Hz Room Size (Coverage Area): Suitable for an area of approximately 36 - 40 square meters Inverter Technology: Yes (uses an Inverter Compressor) Refrigerant: R32 (eco-friendly) Indoor Unit Dimensions (WxHxD): 840 x 246 x 840 mm Outdoor Unit Dimensions (WxHxD): 870 x 650 x 330 mm Panel Dimensions (WxHxD): 950 x 35 x 950 mm
Type of Installation: This is a split-type ceiling cassette system, requiring professional installation into a ceiling void with an external outdoor unit. Color: The visible indoor panel is typically white. 4-Way Airflow: Distributes conditioned air from four directions for uniform and rapid temperature control across the entire space. High Ceiling Mode: Provides powerful cooling and heating up to 4.2m in height, effectively distributing air from ceiling to floor. Independent Vane Control: Allows for individual control of the four airflow vanes to direct air precisely where needed using separate stepping motors. Auto Cleaning Function: The unit can perform self-cleaning to dry the heat exchanger and minimize the formation of mold and bacteria. Gold Fin™ Condenser: The outdoor unit's condenser has an anti-corrosive coating for enhanced durability and longevity. Smart Features: Includes Smart Wi-Fi connectivity and optional human detection and humidity sensors for maximized energy efficiency and comfort.
4-Way Airflow, Auto Cleaning Function, Low Noise Operation
The LG ZTNQ30GNLE0 indoor unit The matching LG outdoor unit (model number typically ZUAC1) A square ceiling panel (white, 950x950 mm) Remote controller (wireless) Owner's Manual Warranty Card
